RGB Pixel Light Square (Standard RGB)
These are the standard RGB Pixel Modules they work the same as RGB strips where they all change together and can be connected to a standard RGB Controller or mixed in with 12v RGB Strips or Modules.
You can order them by the piece or connected together. They run on 12V DC. They are potted with a waterproof epoxy and have a semi clear lens, they can be exposed to weather. ~ they are very easy to work with!
Details / Options
~~These RGB modules can change any color with the use of a standard RGB Controller (they will all change at once so you can't make each one a different color like the digital version
~~If you need help designing your lighting or are not sure how to wire, please check out our How to Install section. If your questions are not answered there, please contact us we would be glad to help!
~~The 12 watt Power Supply (can control up to 40x of these modules) or the 48 watt Power Supply(can control up to 160x of these modules) the 72 watt (can control up to 240x of these modules)~ these are based on the rated power draw~ you may be able to get longer runs than this on a power supply but we can not guarantee it).
Additional Information
Suggested Uses |
Color Changing Signs |
---|---|
Led Color | RGB |
Length Of Strip | modules are every +/- 5.5" on center |
Type of LED | 1x RGB Led / Module |
Viewing Angle (Degrees) | 110°-180° deg |
Mounting Options | Double Sided Tape, Ceiling Mount, Wall Mount |
Waterproof Rating | IP-68 |
Voltage | 12v |
Wattage | .3 watts per module (60mA) |
Power Usage Watts / Foot: Rated (Actual) | x Watts/Foot |
Usage in Amps: Rated (Actual) Red, Blue, Green, White | Per Module R+G+B = .05A (R=.018A) (B =.018A) (G=.018A) |
Number Of Chanels | 3 DMX Channels/Pixel |
Connections Input/Output | Yellow or Black = 12v (+) Red = Red 12v (-) Green =Green 12v (-) Blue = Blue 12v (-) |
Max Connected Strip Length From Each Power Connection | you should supply aditional power every 40-80 modules |
Controllable By | Standard RGB Controller |
Dimmable Range / Steps | Depends on Controller |
Lumens | 9 lm/pixel |
Product Size (L)x(W)x(H) | drill bit size .47" (12mm). max matt thickness .18" (5mm) total hight .91" base .84" (21.5 mm) x .79" (20 mm) |
Strip Width | base width 0.84" (21.5 mm) |
Strip Thickness | base length 0.79" (20 mm) |
Comes With | if you order individual modules they will have 2" wire on both sides of the module |
Available Options | custom spacing (few week lead time) |
