Details
Small size and light weight.
The housing is made from V0 flame retardant PC materials from SAMSUNG/COVESTRO.
Bluetooth 5.0 SIG Mesh with high networking capability is reliable and stable.
Support DMX512/RDM and realize Bluetooth/DMX intelligent switch control.
With soft-on and fade-in dimming function, enhancing your visual comfort.
Compatible with DIM, CT, RGB, RGBW, RGBWY lights to control the output.
Provide the options to set dimming parameters that can meet high-level dimming
requirements in different occasions.
Work with the Super Panel to achieve remote control.
Get control on iOS or Android devices through Bluetooth connection.
Set the soft start time and power-on lighting status
Additional Information
| Product Highlights | Wireless Protocol Type Bluetooth 5.0 SIG Mesh,DMX/RDM Output Voltage 5-24Vdc Input Voltage Range 5-24Vdc Load Current 4A×5CH / 5A×4CH Max. 20A Load Power (0~20W...96W)×5CH Max. 480W Protection Short circuit, overcurrent, overheat, anti-reverse protection Working Temperature -20°C ~ 55°C Dimensions L175×W44×H30(mm) Package Size L178×W48×H33(mm) Weight (G.W) 130g |
|---|---|
| Led Color | RGB |
| Mounting Options | Wall Mount |
| Voltage | 5v-24v |
| Wattage | (0~20W...96W)×5CH Max. 480W |
| Power Input: Connection Type, Voltage, Amperage | (Screw Terminal) |
| Output Connection Type | (Screw Terminal) |
| Controllable By | Bluetooth/DMX |
| Manual | http://www.ltech-led.com/uploads/pdf/en/LED-Controller/B5-DMX-4A-S.pdf |
| Product Size (L)x(W)x(H) | L175×W44×H30(mm) |
| Suggested Accessories | UB4 RGBW Intelligent Touch Panel UB4(Bluetooth + DMX / Programmable) Controller Male power connector for connecting to our power supplies |
