These are great RGB Puck Lights designed for architectural lighting.
These are made to be mounted through a hole (like in the ceiling).
This 9w version has 1x 3in1 Tricolor RGB led.
These are great puck lights that are designed to be controlled with our standard RGB Controllers so they can be used together with 12v RGB Flex Strip or on there own
They can be connected to the Controller using standard 22-4 or 18-4 wire with lengths of up to 50ft. They can also be connected together as each light has in and out ports for connecting multiple lights to the same controller.
Power Requirement: 12VDC
Current: 9W Per Puck Light
Light Dimensions: (1.90" Diameter) x (H) 3.75" (3.98" in Mount)
LED: 1x 3in1 High Power RGB LED
Life Time ®: Expected 20,000 hours life at full power 50,000 on color change modes
Compatible Controller: any of our 12v RGB Controllers or Amplifiers (Common Anode)
You can connect multiple lights to one controller / power supply (just size your power supply/controller to handle the load of devices)
Dimension: (H) 1.25" x (Diameter) (3" hole saw size) (3.66" flange) (1" max ceiling thickness to use spring clips)
Color: White (Paintable)
Eyeball: Adjustable so light can be directed in any direction
Other: Removable Center light holder so you can access the light/wires without removing housing from ceiling
Certifications: CE / RoHS
|Type of LED||1x 9W 3in1 RGB LED|
|Viewing Angle (Degrees)||90 deg|
|Mounting Options||Ceiling Mount|
|Power Usage Watts / Foot: Rated (Actual)||9-10 watts R=.4w B=.5w G=.5w|
|Recommended Power Supply Size||10 watts/puck light|
|Power Input: Connection Type, Voltage, Amperage||Pluggable Screw Terminal|
|Output Connection Type||Pluggable Screw Terminal|
|Dimmable Range / Steps||0-100% via PWM|
|Product Size (L)x(W)x(H)||(1.90" Diameter) x (H) 3.75" (3.98" in Mount) Eyeball Mount (3" hole saw size) (3.66" flange) (H) 1.25" (1" max ceiling thickness to use spring clips)|
