Details
Red SMD LED Modules Mini Coated
~~Ultra-thin SMD LED Modules
~~These are SUPER tiny LED modules with a self stick backing. L=18mm (0.71") W=4mm (0.16") H=3.5mm (0.14") (Wire Between Modules 25mm 1")
~~They are great for lighting tight areas including signs. Very easy to work with!
~~This type has the water-resistant coating.
Additional Information
Suggested Uses |
Great For |
---|---|
Product Highlights | Ultra-thin SMD LED Modules Wide Beam Angle |
Led Color | Red |
Cuttable Every | Module |
Type of LED | 3528 SMD |
Viewing Angle (Degrees) | 120 deg |
Mounting Options | "3M Peel and Stick" Backing on Strips |
Voltage | 12v |
Wattage | .24 |
Dimmable Range / Steps | 0-100% via PWM |
Lumens | Abrox 12 Lumens / Module |
Weight / Item | .03 |
Product Size (L)x(W)x(H) | L=18mm W=4mm H=3.5mm (Wire Between Modules 25mm 1") |
Available Options (may not be in stock) | water resistant IP-65 |
Available Options | Red, Blue, Green, White, Warm White, Amber |
